Frequency Range: UHF: 403 - 470 MHz ; VHF: 136 - 174 MHz
Storage Channel: 16
Dimensions: 137mm x 57.5mm x 37.5mm
Weight: 420g
1.Features
The GP328 is the two-way radio solution for professionals who need to stay in contact. This practical radio can easily increase productivity by keeping users communicating, yet streamlines their radio use – allowing them to concentrate on the job at hand. With the GP328, communication could not be easier. The GP328 comes with 2 models – 4 channel and 16 channel model to organise work groups with ease and efficiency.
GP328 KEY FEATURES AND BENEFITS
X-PAND™ AUDIO TECHNOLOGY
Motorola’s special voice compression and expansion technology called X-PAND enables crisper, clearer and stronger audio quality, allowing you to keep communicating in any noisy environment.
LED BATTERY GAUGE
Tri-colour LED to indicate battery strength, avoiding failed communication with early warning low battery strength.
EMERGENCY SIREN
Easy-to-access, one-touch button with piercing alarm to seek help in a critical situation.
SWITCHABLE RF POWER LEVEL
Optimise coverage and conserve battery consumption.
PROGRAMMABLE CHANNEL SPACING OF 12.5/25KHZ MODE: Flexible and easy migration of channel spacing requirements in any situation.
REPEATER/TALKAROUND ENABLE/DISABLE: Freedom to communicate via a repeater for wide area coverage; or bypass a repeater and talk directly to another unit for easy local unit-to-unit communications
TIGHT/NORMAL SQUELCH: Flexibility to switch to tight squelch to filter out excessive noise; or normal squelch for normal coverage.
FIELD RETROFIT OPTION BOARDS: Easy to install, affordable add-on functionality whenever your needs arise. Option Boards are available for:
• DTMF Decode for incoming calls capability;
• Voice Storage for recording and playing back voice messages.
INTERNAL VOICE OPERATED TRANSMISSION (VOX): For hands-free operation, activate this option by speaking with the optional headsets.
BATTERY OPTIONS: Flexible choice of batteries – NiDC Battery – High Capacity NiMH Battery – Ultra High Capacity NiMH Battery – Lithium Ion Battery
TONE TAGGING: Assign 8 different ringing tones to 8 specific users/talkgroups making audio caller identification to these 8 groups possible.
ENHANCED SIGNALLING FEATURES MDC1200: – Call Alert Decode – Voice Selective Call Decode – Selective Radio Inhibit Quick Call ll – Call Alert Decode – Voice Selective Decode Dual Tone Multiple Frequency (DTMF) Signalling Encode.
2.Specifications
General |
|
Frequency Range |
UHF: 403 - 470 MHz VHF: 136 - 174 MHz |
Memory Channel |
16 |
Channel spacing |
2.5/5/6.25/10/12.5/20/25KHz |
Operating Temperature |
-20℃~+50℃ |
Operating Voltage |
DC 7.4V |
Demission |
137mm x 57.5mm x 37.5mm |
Weight |
420g |
Battery Capacity |
2500mAh lithium |
Transmission Part |
|
Output power |
≤5W |
Maximum Fequency Offset |
≤5KHz / ≤2.5KHz |
FM Noise |
≤-45dB |
Modulation Distortion |
≤5% |
Modulation |
16KΦF3E / 8KΦF3E |
CTCSS/DCS |
0.75KHz ±50Hz,0.37KHz ±30Hz |
Reception Part |
|
Sensitivity |
-122dBm |
Audio Power |
1W |
Audio Distortion |
<5% |
Adjacent Channel Selectivity |
≤65dB, ≤60dB |
Spurious Rejection |
≥65dB |
