Frequency Range: 350-470 MHz, 800 MHz
Dimensions: 132 x 59 x 34mm
Weight (with standard battery): 292g
Dust and Water Intrusion: IP67 Capable
1.Features
The MTP6000 series of TETRA portables lets your front line officers respond to incidents equipped with the collective intelligence of the entire team and the community. With integrated multimedia capabilities, MTP6000 radios provide you with a platform for capturing and sharing critical intelligence across the force. Designed for operation in high stress environments, MTP6000 radios offer unmatched usability and performance, ensuring that front line officers can focus on the job, not the technology
DIGITAL MEDIA INTELLIGENCE GATHERING
From enhanced intelligence gathering to efficient reporting, the multimedia capabilities of the MTP6000 radios create many possibilities for public safety.
With an integrated high-resolution camera, the first of its kind in a TETRA radio, the MTP6750 makes it easy for law enforcement officers to capture critical crime scene information. Building a case for prosecution will typically involve bringing together digital evidence from a wide range of sources such as agency radio traffic and digital video footage. The MTP6750 attaches meta-data to each image, enhancing investigative capabilities and enabling investigators to reconstruct the events that took place during a critical incident.
FROM INTELLIGENCE TO ADMISSIBLE PHOTOGRAPHIC EVIDENCE
To be admitted in court, photographs must be verified as authentic. The MTP6750 attaches a Digital Fingerprint to every captured image to verify its authenticity. For added security, we’ve ensured that Digital Fingerprint is tamperproof and that it can be safely stored in the radio. Capturing images is just the beginning. To simplify the discovery process, photographic evidence needs to be stored and catalogued in a logical and structured manner. With our Photograph and Intelligence Communication System (PICS), you can streamline the process of managing and sharing images in a secure environment.
PROTECT YOUR INVESTMENT FROM THE UNEXPECTED
Service from the Start* provides complete peace of mind with mission-critical support for your TETRA radios. It offers multi-year coverage against normal wear and tear, fast repair turnaround times and expert telephone technical support; all backed by Motorola’s globally integrated services infrastructure, highly qualified support technicians and certified repair facilities. Service from the Start with Comprehensive Coverage provides even greater support with the additional benefit of coverage for internal and external components damaged through accidental breakage. With Service from the Start you’re covered – keeping your devices running and in the hands of the user.
2. Specifications
GENERAL SPECIFICATIONS | |
Frequency | 350-470 MHz, 800 MHz |
Dimensions (HxWxL) | 132 x 59 x 34mm (With standard battery)) |
Weight with battery: | 292g (with standard battery) |
TETRA SERVICES | |
Transmitter RF Power | Class 31 (2.8W) Class 3L (1.8W) Class 4 (1W) |
Adaptive Power Control | Per EN 300 392-2 |
Receiver Static Sensitivity | 350-470 MHz: -116dBm (min); -118dBm (typical) 800 MHz: -114dBm (min); -116dBm (typical) |
Receiver Dynamic Sensitivity | 350-470 MHz -107dBm (min); -109dBm (typical) 800 MHz: -105dBm (min); -107dBm (typical) |
VOICE | |
Full Duplex Call | TMO: Private, PABX, PSTN, emergency |
Half Duplex call | TMO: Private, group, emergency |
DMO: Private, group, emergency | |
Other Voice Functions | Inter-MNI ; Gateway; Repeater ; PTT double push ; Pre-emptive priority calls |
DMO REPEATER | |
DMO repeater mode features and functions | ETSI type 1A DMO Repeater for channel efficient operation |
Repeats DMO voice and tone signalling on selected talkgroup | |
Repeats SDS and Status messaging on selected talkgroup | |
Transmission of Repeater Presence Signal | |
Emergency Call (Pre-emptive Priority Call) | |
Monitoring of and participation in calls whilst in Repeater mode | |
BLUETOOTH | |
Bluetooth Versions Supported | Bluetooth 2.1 + EDR, Bluetooth 4.0, Bluetooth Smart (BTLE) |
Bluetooth Security | Bluetooth 2.1 Introduces Mandatory Encryption with Secure Simple Pairing (SSP), Easier Pairing and Preventing Sniffing/Hacking |
Bluetooth Audio Profiles | Headset Profile (HSP), Fast PTT with Motorola Solutions Accessories |
Bluetooth Data Profiles | Serial Port Profile, Dial Up Networking Profile, Discovery Mode, Generic Access Profile, Generic Attributes Profile (GATT), Heart Rate Profile, Battery Service Profile, Devices Info Profile |
SATELLITE / OUTDOOR NAVIGATION SERVICE | |
Constellations Supported | GPS, BeiDou/Glonass |
Antenna | Integrated Internal Antenna |
Simultaneous Satellites | 12 |
GNSS Tracking Sensitivity, dBm | GPS: -160 dBm (guaranteed); -161 dBm (typical) |
Protocols | ETSI LIP (Short and Long), Motorola LRRP |
3. Shipping Terms
Shipments are typically arranged using the following methods: DHL, UPS, FedEx, TNT, EMS, and other similar services, depending on the destination country and region. DHL and UPS are generally prioritized due to their high efficiency and reliability. Should you require alternative shipping options, please kindly inform us, and we will be happy to accommodate your request accordingly.
4. Payment Terms
EEC supports both online and offline payment methods:
For online payments, we accept PayPal, which uses advanced encryption to ensure secure transactions. Sellers can issue invoices to guide customers through the payment process.
For offline payments, we accept Telegraphic Transfer (TT), Western Union, and MoneyGram, offering global convenience and simplicity.
