Frequency Range: VHF 136-174Mhz, UHF403-470Mhz
Storage Channel: 16
Weight: 406g
Dimensions: 127.7x61.5x39 mm
1. Features
CONNECT AND COORDINATE CREWS
When you need a simple, reliable, cost-effective communication solution to help multiple work crews connect, coordinate and collaborate, XiR P3688 two way portable radios are made to get the job done right. With their easy-to-use ergonomics and crisp, clear audio, now your teams can work more efficiently. Unleash the power of your XiR P3688 radios with Motorola Original® accessories. They’re the only accessories designed, built and tested with your radio to optimize its performance. (See separate accessory fact sheet for full portfolio).
IMPROVE THE WAY THEY WORK
A construction worker carries his CP200D as an essential part of his toolkit. The digital technology gives him excellent coverage across the entire site. And it has significantly better battery life too, so he knows he’ll have reliable voice communications all day long. The manufacturing team in a parts factory relies on CP200D portables to coordinate operations. The digital noise-cancelling software filters out the worst of the background noise, allowing them to hear clearly over loud machinery. Factory capacity is expanding, so they’re running MOTOTRBO Dual Capacity Direct Mode, which can fit twice as many calls into the same spectrum. A security guard uses his CP200D to alert the control room to some suspicious activity. The radio’s intuitive design is easy to use in the dark, and even when he speaks softly, he knows that the digital AGC (Automatic Gain Control) will automatically boost the volume so he’s heard clearly back in the office. And if it comes to the worst, he can use one of the programmable side buttons to call for help – with one touch.
MANAGE YOUR FLEET MORE EFFICIENTLY
We’ve designed the CP200D to be as efficient to operate as it is cost-effective to buy. That’s why we’ve integrated the powerful fleet management capabilities of Motorola’s Radio Management solution into every radio. Gain even greater efficiency when you migrate to digital. Your radio will operate up to 40% longer than analog on the same battery – and you get twice the capacity from the same 12.5 kHz channel, using our Dual Capacity Direct Mode feature.
INTEGRATE YOUR DEVICES SEAMLESSLY
Make sure your new CP200D radios are ready when you are. We can bring together the right experts and processes to help you integrate CP200D radios into your business, quickly and cost-effectively. This includes Site Survey and Device Programming.
GET DURABILITY THAT ENDURES
The CP200D is made to last. It is backed by a two-year standard warranty and a minimum one-year warranty for Motorola-branded accessories. It is rated IP54 (splashproof, virtually dustproof), so it can be used even in harsh environments. Moreover, the design has been proven tough in Motorola’s grueling Accelerated Life Test program, in which the radio must survive a simulated 5 years of hard service before it is accepted. You can be confident in the durability of your CP200D.
Features
• Analog / Digital
• Voice Communications
• Dual Capacity Direct Mode
• Digital Mobile Radio (DMR) Standards Compliant
• Narrowbanding Compliant
• IP54 Rated
OPTIONS
• Radio Management Suite
• Transmit Interrupt (decode only)
2. Specifications
Main Specifications |
|
Channel Capacity |
16 |
Power Output |
VHF:1-5W UHF:1-4W |
Frequency Range |
VHF:136-174MHz UHF: 403-470MHz |
Dimensions (HxWxL) with 1400mAh NI-MH battery with 1600mAh Li-ion battery with 2200mAh Li-ion battery |
127.7x61.5x42.0 (mm) 127.7x61.5x39.0 (mm) 127.7x61.5x44.0 (mm) |
Weight with 1400mAh NI-MH battery with 1600mAh Li-ion battery with 2200mAh Li-ion battery |
406g 341g 346g |
Power Supply |
7.5V (theoretical data) ±20% |
Battery |
|
Average battery life at 5/5/90 duty cycle with battery saver enabled in carrier squelch and transmitter in high power |
|
NiMH (1400mAh) Battery Li-ion (1600mAh) Battery Hi-Cap (2200mAh) Li-ion Battery |
Analog: 9 hrs Digital: 12.5 hrs Analog: 10.5 hrs Digital: 13.5 hrs Analog: 14.5 hrs Digital: 18.5 hrs |
Receiver |
|
Frequency |
VHF:136-174MHz UHF: 403-470MHz |
Channel Spacing |
12.5kHz / 20kHz / 25kHz |
Frequency Stability (-30℃,+60℃,+25℃ Ref) |
±0.5 ppm |
Analogue Sensitivity (12dB SINAD) |
0.3uV / 0.22uV (typical) |
Digital Sensitivity (5% BER) |
0.3uV / 0.19uV (typical) |
Intermodulation |
-70dB |
Adjacent Channel Selectivity |
45dB @ 12.5kHz / 70dB @ 20/25kHz |
Spurious Rejection |
-70 dB |
Rated Audio |
0.5W |
Audio Distortion@ Rated Audio |
5% (3% typical) |
Hum and Noise |
-40dB @ 12.5kHz / -45dB @ 20kHz/25kHz |
Audio Response |
TIA603D |
Conducted Spurious Emisson |
-57dBm |
Transmitter |
|
Frequency |
VHF:136-174MHz UHF: 403-470MHz |
Channel Spacing |
12.5kHz / 25kHz |
Frequency Stability (-30℃, +60℃, +25℃ Ref) |
±0.5 ppm |
Power Output |
VHF:1-5W UHF:1-4W |
Modulation Limiting |
±2.5kHz @ 12.5kHz / ±4.0kHz @ 20kHz / ±5.0kHz @ 25kHz |
FM Hum and Noise |
-40dB @ 12.5kHz / -45dB @ 20/ 25kHz |
Conducted/Radiated Emission |
-36dBm<1GHz / -30dBm>1GHz |
Adjacent Channel Power |
60dB @ 12.5kHz / 70dB @ 20/ 25kHz |
Audio Response |
TIA603D |
Audio Distortion |
<3% (typical) |
Digital Vocoder Type |
AMBE +2 |
Digital Protocol |
ETSI TS 102 361-1, -2, -3 |
Environmental Specifications |
|
Operating Temperature |
-30℃ / +60 ℃ |
Storage Temperature |
-40℃ / +85 ℃ |
Temperature Shock |
Per MIL-STD |
Humidity |
Per MIL-STD |
Water and Dust Intrusion |
IEC60529-IP54 |
