Frequency Range: VHF 136-174MHz; UHF 400-527MHz
Storage Channel: 64
Dimensions: 279.4 x 228.6 x 101.6mm
Weight: 10 lbs (4.54 kg)
1. Features
WHETHER YOU WANT TO ELIMINATE DEAD ZONES OR EXPAND COVERAGE TO REMOTE LOCATIONS, COUNT ON THE SLR 1000. COMPACT, EASY TO INSTALL, AND DESIGNED TO WORK INDOORS OR OUT, IT’S BUILT TO GROW AS YOUR NEEDS DO.
Keeping your team connected requires uninterrupted radio coverage. But often, network dead zones and remote locations present barriers to seamless communication.
Unlike traditional repeaters, the SLR 1000 is IP65-rated for dust and water protection, so you can deploy on campuses, in parking garages, and across other outdoor locations. The compact size gives you more installation options, such as mounting on walls or poles. And a low power, fanless design uses less space and energy, saving you money right from the get-go.
As your organization grows, the SLR 1000 can grow with it. It works with both conventional and trunking systems supporting voice and data, so moving to a bigger system won’t always require buying a bigger repeater.
Above all, it’s technology you can trust. With more than 10 years of experience in DMR, you can rely on Motorola Solutions and proven MOTOTRBO™ technology to get the job done.
The SLR 1000 makes it simple. With a compact design, you can mount it on walls or poles. And since the SLR 1000 doesn’t require cooling from HVAC, you have more placement options. All while eliminating the planning headaches and added costs that come with HVAC.
2. Specifications
General Specifications |
|
Frequency Range |
VHF:136MHz-174MHz |
Memory Channel |
64 |
Channel Spacing |
25 / 12.5 kHz |
Power Output |
1 - 10W |
Operating Voltage |
12 V (11.0-15.5 V) |
Input Power Modes |
DC only, Optional AC/DC Power Supply Available |
Dimensions (L×W×H) |
11 x 9 x 4 in (279.4 x 228.6 x 101.6 mm)* |
Weight |
10 lbs (4.54 kg) |
Communication Range |
about 10-20km |
Sealing |
IP65, MIL-STD |
Dust |
Meets MIL-STD 810-C,D&E and TIA/EIA 603 |
Transmitter Specifications |
|
Channel Spacing |
25 / 12.5 kHz |
FM Hum & Noise |
- 40dB @ 12.5kHz; - 45dB @ 20/25kHz |
Conducted/Radiated Emissions |
- 36dBm < 1 GHz; - 30dBm < 1 GHz |
Adjacent Channel Power |
- 60dBm @ 12.5kHz ; - 70dBm @ 20/25kHz |
Receiver Specifications |
|
Frequency Stability |
+/- 0.5 ppm |
Channel Spacing |
25 / 12.5 kHz |
FM Modulation |
12.5 kHz : 11K0F3e 25 kHz: 16K0F3e |
Adjacent Channel Selectivity |
60 Db @ 12.5 kHz, 70 dB @ 20/25kHz |
Audio Response |
+ 1, -3dB |
Digital Vocoder Type |
AMBE+2 |
Digital Protocol |
eTSI-TS102 361-1 |
