Kenwood Analogue Mobile Two Way Radio 25W UHF TM481A

1. Features

Whatever the mission, wherever you go, KENWOOD’s TM-281A is a radio you can count on. This compact transceiver delivers powerful mobile performance and such advanced features as multiple scan functions and memory names. High-quality audio is assured by the large speaker. Naturally, MIL-STD compliant toughness ensures rugged reliability. And operating ease is second to none: illuminated keys and a large LCD with adjustable backlighting make for user-friendly operation day or night.

Rugged, Compact Construction

The TM-281A is tough enough for off-road assignments: it meets the strict U.S. Department of Defense MIL-STD 810 C, D, E, F & G environmental standards for vibration and shock. Installation is easy due to its compact dimensions: 160 (W) x 43 (H) x 126 (D)* mm .

High Power Output

Even with its compact size, the TM-281A delivers up to 65 watts – the sort of RF power you want in the wilderness – with a choice of High/Low output. A hand microphone is also supplied as standard.

Alphanumeric LCD And Illuminated Keypad

The vivid amber LCD display comes with a 32-step brightness control to suit any ambient light conditions. It displays up to 6 large alphanumeric characters. The front panel keypads are also illuminated for ease of use.

Impressive Front Speaker

The large oval speaker (58 x 35 mm) mounted in the front ensures every message is heard loud and clear.

Memory Name Function

Up to 100 memory channels can be identified with a maximum of 6 alphanumeric characters each. (200 channels are available if the memory name function is not used.)

200 Memory Channels Plus 1 Call-Channel

Each of the memory channels can be used to store transmit and receive frequencies independently. Additionally, memory data can be edited and stored on a computer*.

*Requires USB Programming Cable KPG-46U, and Memory Control Software MCP-1A (Ver.3.0 or later); consult your local dealer for details on purchasing these options.

Multiple Scan Functions

Included as standard are VFO scan, memory scan, call scan, Tone/CTCSS scan and DCS scan – with TO (Time-operated), CO (carrier-operated) and seek scan resume modes. Also priority scan is available to check the Priority channel every 3 seconds.

CTCSS & DCS  ENCODER / DECODER

The built-in CTCSS and DCS encoder/decoder covers 42 CTCSS sub-tone frequencies and 104 DCS sub-tone frequencies.

Other Functions

- Power-on Message

- Wide/Narrow Deviation Selection (per channel)

- 1750 Hz Tone Burst

- Automatic Simplex Checker

- Reverse Function

- Auto Repeater Offset

- Beep On/Off

- Auto Power Off

- Time-Out Timer

- Channel Display Mode

- Busy Channel Lockout

- Memory Channel Lockout

- MR-shift

- Direct Frequency Entry

- Key Lock

2. Specifications

GENERAL
Frequency Range	VHF	136 - 174 MHz
	UHF	400-470 MHz
Mode		F3E (FM)
Power Requirement		13.8 V DC ±15 %, negative ground
Curent Drain	Transmit	Less than 14 A (High), less than 8 A (Low)
	Receive	Less than 1 A
Operation Temperature Range		-20 °C ~ +60 °C
Antenna Impedance		50 Ω
Microphone Impedance		600 Ω
Frequency Tolerance		±2.5 ppm (-20 °C ~ +60 °C)
Dimensions (W x H x D), (Projections included)		160 x 43 x 126 mm 161 x 43 x 170.5 mm
Weight		1.13 kg
TRANSMITTER
RF Power Output Hi / Lo		65 W / 25 W
Modulation		Variable reactance modulation
Maximum Frequency Deviation		Wide: ±5 kHz, Narrow: ±2.5 kHz
Modulation Distortion		Less than 3 % (300 Hz - 3 kHz)
RECEIVER
Circuitry		Double super heterodyne
Intermediate	1st IF	49.95 MHz
	2nd IF	450 kHz
Sensitivity (12 dB SINAD)		Less than 0.18 μV (Narrow: less than 0.22 μV)
Squelch Sensitivity		Less than 0.1 μV
Selectivity	-6 dB	More than 12 kHz (Narrow: more than 10 kHz)
	-60 dB	Less than 30 kHz (Narrow: less than 24 kHz)
Audio Output Power		More than 2 W (5 % distortion)
